| Combined Vacuum Jet Truck ISUZU (8,000 Litres) | |||
| General | Vehicle Brand | SPV | |
| Chassis Brand | ISUZU | ||
| Overall Dimension | 8150 * 2500 * 3150 mm | ||
| GVW / Kerb Weight | 18,000 kg / 9,130 kg | ||
| Cab | Cab Capacity | 2 persons seats with 1 sleeper | |
| Air Conditioner | W/ air conditioner | ||
| Engine | Fuel Type | Diesel | |
| Engine Brand | ISUZU Engine | ||
| Power | 205 Hp (150 KW) | ||
| Displacement |
5193 ml | ||
| Emission Standard |
Euro V | ||
| Chassis | Drive Type |
4X2, left hand drive |
|
| Transmission |
Manual, 6-speed forward, 1 reverse | ||
| No. of Axles |
2 | ||
| Tyre Specification |
10.00R20 | ||
| Tyre Number |
6 tyres and 1 spare tyre | ||
| Max Speed |
95 km/h | ||
| Paint |
Metallic paint |
||
| Superstructure |
Water Tank |
Tank Capacity |
2,000 litres (about 500 gallons) |
| Tank Material |
Carbon steel |
||
| High Pressure Pump |
Chinese high quality PINFL |
||
| Flow Speed |
153 L/min |
||
| High Pressure Hose |
80m |
||
| Nozzles |
A cluster of nozzles included |
||
Sewer Tank |
Tank Capacity |
6,000 Litres (about 1600 gallons) |
|
| Tank Material |
Carbon steel |
||
| Vacuum Pump |
Italy brand JUROP |
||
| Flow Rate |
11000 L/min |
||
| Rear door can be hydraulic opened for complete discharge of solid stuff. |
|||
| All other standard accessories: Tool kit, English manual…… |
|||
| Optional | ** Tank material could be mild steel, stainless steel… ** Italy vacuum pump is available. |
||
