Garbage compactor is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing re-pollution. When arriving at destination, the garbage can be dumped completely. It is ideal solution for solid waste collection.
The operation system could be manual or electrical control.
Features:| Garbage Compactor Truck ISUZU (12 m³ trash compactor truck) |
||
| General | Vehicle Brand | SPV |
| Chassis Brand | ISUZU | |
| Overall Dimension | 8920 * 2500 * 3280 mm | |
| GVW / Kerb Weight | 16,000 kg / 10,100 kg | |
| Cab | Cab Capacity | 3 persons allowed with 1 sleeper |
| Air Conditioner | W/ air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU engine, 4HK1-TCG40 | |
| Power | 190 Hp (139 KW) | |
| Displacement |
5193 ml |
|
| Emission Standard |
Euro V |
|
| Chassis | Drive Type |
4X2, left hand drive |
| Transmission |
ISUZU gear box, 6 speed forward, 1 reverse |
|
| No. of Axles |
2 |
|
| Tyre Specification |
10.00-20 |
|
| Tyre Number |
6 tyres and 1 spare tyre |
|
| Max Speed |
95 km/h |
|
| Paint |
Metallic paint |
|
| Superstructure |
Waste Box Capacity |
12 m³ |
| Waste Box Material |
Carbon steel |
|
| All other standard accessories: Tool kit, English manual…… |
||
| Optional | **Various rear loading mechanism: container lifting; hopper flip; skip loader… **Electronic operating system |
|
